Warbird Photographs


WWII German Aircraft Photographs - Fighters

Focke Wulf 190 - Page 26

FW190A5-II.5.JG54-Black(5+-)-Flown-By-Oberleutnant-Max-Stotz-(189-Total-Victories)-At-Siverskaya-Airfield-Leningrad-Area-Russia-June-1943-26f-s.jpg (80K) FW190A-5 II.5./JG 54 Black(5+-) Flown By Oberleutnant Max Stotz (189 Total Victories) At Siverskaya Airfield, Leningrad Area, Russia June, 1943
 [742x494] (80K)

FW190A5-II.5.JG54-Black(5+-)-Flown-By-Oberleutnant-Max-Stotz-(189-Total-Victories)-At-Siverskaya-Airfield-Leningrad-Area-Russia-June-1943-26af-s.jpg (87K) FW190A-5 II.5./JG 54 Black(5+-) Flown By Oberleutnant Max Stotz (189 Total Victories) At Siverskaya Airfield, Leningrad Area, Russia June, 1943
 [1000x627] (87K)

FW190A5-with-MG151-20mm-Wing-Root-Cannons-&-MGFF-20mm-Outer-Wing-Cannons-Ready-For-Taxi-to-Runway-to-Start-Mission-Amid-Cut-Tree-Branches-Used-For-Parking-Camouflage-30f-s.jpg (35K) FW190A-5 with MG151 20mm Wing Root Cannons & MGFF 20mm Outer Wing Cannons Ready For Taxi to Runway to Start Mission Amid Cut Tree Branches Used For Parking Camouflage
 [700x242] (35K)

FW190-A5U12-2.JG11-2nd-Staffel-Man-in-Black-Sitting-On-Uncle-Sam's-Top-Hat-&-Hand-On-Side-of-Face-Cowling-Emblem-&-2-MG151-Wing-Cannons-&-2-WB151A-Dual-MG151-Wing-Pods-Holstein-Germany-Fall-1944-31f-s.jpg (63K) FW190A-5/U12 I.2./JG 11 2nd-Staffel Man In Black Sitting On Uncle Sam's Top Hat & Hand On Side of Face Cowling Emblem & Two MG151 20mm Wing Cannons & Two WB151A Dual MG151 20mm Cannon Wing Pods At Holstein, Germany Fall-1944
 [700x471] (63K)

FW190-A5Y-3.Jagd-Division-Green(X+-)-WrkN410054-with-'England Blitz'-NachtJagd-Emblem-On-Cowling-&-with-300-Liter-Belly-Tank-Flown-By-Oberst-Walter-Grabmann-At-Deleen-Holland-1943-1944-33f-s.jpg (57K) FW190A-5/Y 3.Jagd-Division Green(X+-) WNr.410054 with 'England Blitz' NachtJagd Emblem On Cowling &-with 300 Liter Belly Fuel Tank Flown By Oberst Walter Grabmann At Deleen, Holland 1943-1944
 [700x478] (57K)

FW190-A5-34f-s.jpg (52K) FW190A-5 with No MGFF 20mm Outer Wing Cannons & Pilot Sitting On Nose with Flight Jacket & Signal Flares On Leg Band & Two Mechanics Waiting On the Wing For Next Alert
 [700x414] (52K)

FW190-A5U3-10.(Jabo)JG54-ex-10.(Jabo)JG26-Black(4+c)-WrkN0150532-with-Small-Black-Bomb-Emblem-On-Rear-Fuselage-&-with-SC500-500Kg-Bomb-Taxiing-Out-For-Raid-On-Britain-From-St.-Omer-Wizernes-France-Fall-1942-35f-s.jpg (39K) FW190A-5/U3 10.(Jabo)/JG 54 ex-10.(Jabo)/JG 26 Black(4+<) WNr.150532 with Small Black Bomb Emblem On Rear Fuselage & with SC500 500Kg Bomb On ETC501 Fuselage Bomb Rack Taxiing Out For Raid On Britain From St. Omer, Wizernes, France Fall 1942
 [576x255] (39K)

FW190F8R1tp-(CM+WL)-WrkN580383-1st-Made-From-FW190A5U13tp-By-Changing-to-MG131-13mm-Nose-Guns-&-Carrying-Two-SC50-50Kg-Bombs-On-ETC50s-Under-Each-Wing-&-One-SC500-500Kg-Bomb-On-ETC501-Fuselage-Rack-36f-s.jpg (36K) FW190F-8/R1/tp (CM+WL) WNr.580383 1st Made From FW190A-5/U13/tp By Changing to MG131 13mm Nose Guns & Carrying Two SC50 50Kg Bombs On ETC50 Bomb Racks Under Each Wing & One SC500 500Kg Bomb On ETC501 Fuselage Rack
 [1003x625] (36K)

FW190-A6-with-Belt-Fed-Outer-Wing-MG151-20mm-Cannons-Warming-Up-Engine-In-Forest-Dispersal-2f-s.jpg (49K) FW190A-6 with Belt-Fed Outer Wing MG151 20mm Cannons Warming Up Engine In Forest Dispersal
 [700x356] (49K)

FW190A7-II.7.JG26-(SV+DA)-WN340001-Brown(4+-)-with-21-Kills-Pilot-7th-Staka-Oblt.-Waldemar-'Waldi'-Radener-&-A8-(Br5+-)-WN730995-&-A8-(Br7+-)-WN170716-&-1-Other-&-Belly-Tanks-Cambra-Sud-France-Early-June-1944-4f-s.jpg (46K) FW190A-7 II.7./JG 26 (SV+DA) WNr.340001 Brown(4+-) with 21 Victories Flown By 7th-Staffelkapitan Oberleutnant Waldemar 'Waldi' Radener & FW190A-8 (Brown5+-) WNr.730995 & FW190A-8 (Brown7+-) WNr.170716 & One Other Aircraft & All With Belly Fuel Tanks Over Cambra-Sud, France Early June 1944
 [600x396] (46K)

FW190-A8-with-One-Ruhrstahl-X4-Air-to-Air-Wire-Guided-Missile-Under-Each-Wing-with-a-20Kg-Warhead-&-Range-of-3000-Yards-&-After-Launch-the-Control-Wires-Spooled-Off-Bobbins-On-2-of-4-Missile-Fintips-1f-s.jpg (52K) FW190A-8 with One Ruhrstahl X4 Air-to-Air Wire-Guided Missile Under Each Wing with a 20Kg Warhead & Range of 3000 Yards & After Launch the Control Wires Spooled Off Bobbins On 2 of 4 Missile Fintips
 [750x454] (52K)

FW190-A8R8-II.4.(Sturm)JG300-White(5+-)-WN681366-Pilot-Uffz.-Friedrich-Alten-&-White(18+-)-&-White(15+-)-with-Armored-Side-Windows-&-Cockpit-Sides-&-No-Nose-Guns-At-Holzkirchen-South-of-Munich-Germany-August-1944-3f-s.jpg (60K) FW190A-8/R8 II.4.(Sturm)/JG 300 White(5+-) WNr.681366 Flown By Unteroffizier Friedrich Alten & White(18+-) & White(15+-) with Armored Side Windows & Cockpit Sides & No MG131 13mm Nose Guns At Holzkirchen, South of Munich, Germany August 1944
 [624x425] (60K)

FW190-A8-I.3.JG301-Yellow17-WrkN380374-Defense-of-the-Reich-JG301-Yellow-Red-Fuselage-Band-with-FuG16ZY-Morane-Antenna-&-DF-Antenna-At-Pilsen-Czechoslovakia-April-1945-9f-s.jpg (58K) FW190A-8 I.3./JG 301 Yellow 17 WNr.380374 Defense-of-the-Reich JG 301 Yellow-Red Fuselage Band with FuG-16ZY Morane Antenna & DF Antenna At Pilsen, Czechoslovakia April 1945
 [800x526] (58K)

 [567x750] (96K)

FW190A8-IV.14.Unknown-Unit-(Blue17+Black~)-WrkN170412-Abandoned-At-Berlin-Tempelhof-Airport-Repair-Center-Captured-By-VVS-(Voyenno-Vozdushnye Sily)-Russia-Air-Force-April-1945-Note-2-Yak9s-At-Upper-Right_17f-s.jpg (50K) FW190A-8 IV.14./Unknown-Unit (Blue17+Black~) WNr.170412 Abandoned At Berlin Tempelhof Airport Repair Center Captured By VVS (Voyenno-Vozdushnye Sily) Russia Air Force April 1945, Note: Two Yak-9s At Upper Right
 [1000x460] (50K)

FW190 BMW801 Engine Cylinder Head Assembly Line
 [1024x587] (88K)

 [450x645] (66K)

 [511x731] (88K)

 [332x724] (97K)
